Дополнительная информация о товаре:
| ЧИП | Intel i350AM2 |
|---|---|
| СТАНДАРТ | Gigabit Ethernet 1000Base-T / Fast Ethernet 100Base-TX / Ethernet 10Base-T |
| ИНТЕРФЕЙС | PCI-E x4 |
| ПОРТЫ / РАЗЪЕМЫ | 2x Shielded RJ45 |
| СКОРОСТЬ ПЕРЕДАЧИ ДАННЫХ : | |
| 1000 Mb/s, 100 Mb/s and 10 Mb/s in simplex mode per port. | |
| 2000Mb/s 200 and 20 Mb/s in full duplex mode per port. | |
| МАКСИМАЛЬНАЯ ДИСТАНЦИЯ ПЕРЕДАЧИ ДАННЫХ | |
| 100Base-T Category 3, 4, 5 maximum 50m | |
| 100Base-Tx Category 5 maximum 50m | |
| 1000Base-T Category 5E maximum 100m | |
| ИНДИКАТОРЫ | |
| три светодиода на порт | |
| Link/Act LED — Turn on any Link speed , Blinks on Activity | |
| Bypass LED — Turns on bypass | |
| Disconnect LED — Turns on disconnect | |
| УПРАВЛЕНИЕ | n/a |
| ПРОТОКОЛЫ | |
| FCC Part 15, Subpart B Class A | |
| Conducted Emissions | |
| Radiated Emissions | |
| CE EN 55022 | 1998 Clas Amendments A1 2000; A2 |
| Conducted Emissions | |
| Radiated Emissions | |
| CE EN 55024 | 1998 Amendments A1 2000; A2 |
| Immunity for ITE Amendment A1 | 2001 |
| CE EN 61000-3-2 2000, Class A | |
| Harmonic Current Emissions | |
| CE EN 61000 3-3 1995, Amendment A1 | 2001 |
| Voltage Fluctuations and Flicker | |
| CE IEC 6100-4-2 | 1995 |
| ESD Air Discharge 8kV. Contact Discharge 4kV. | |
| CE IEC 6100-4-3:1995 | |
| Radiated Immunity (80-1000Mhz), 3V/m 80% A.M. by 1kHz | |
| CE IEC 6100-4-4:1995 | |
| EFT/B | Immunity to electrical fast transients 1kV Power |
| Leads, 0.5Kv Signals Leads | |
| CE IEC 6100-4-5:1995 | |
| Immunity to conductive surges COM Mode; 2kV, | |
| Dif. Mode 1kV | |
| CE IEC 6100-4-6:1996 | |
| Conducted immunity (0.15-80 MHz) 3VRMS 80% A.M. | |
| By 1kHz | |
| CE IEC 6100-4-11:1994 | |
| Voltage Dips and Short Interruptions | |
| V reduc >95%, 30% >95% Duration 0.5per, 25per, 250per | |
| ПОДДЕРЖКА ОС | Linux |
| ПОТРЕБЛЕНИЕ ЭНЕРГИИ | до 4.56W |
| КОМПЛЕКТ ПОСТАВКИ | инструкция по установке, драйвер, лицензия |
| ГАБАРИТЫ | 167.64 x 68.91 мм |
| ВЕС | 130 гр. |
